产品名称

AR200-FD

The AR200 ultrasonic anemometer series give precise and maintenance-free measurement of wind speed and wind direction. With its aluminium-alloy and teflon-coated housing, the AR200-FD is well-suited for use wind power industry. The AR200-FD and AR200 anemometers are also used for wind measurement applications in coastal and marine, container ports / wharves, electric power transmission stations, airports, bridge and tunnel and urban environment monitoring Features . Aluminum/Teflon alloy construction . Lower power dissipation . Optional heating function . No moving parts and maintenance-free . High accuracy . Optional to remove heating function . Optional to remove analog output
Numbering
没有此类产品
Product description

Basic Information

IP  Class

IP66

Dimensions

height 185 mm   width 160 mm

Weight

1.2 Kg

Analog outputs

4 … 20 mA,1 … 5V

Interface

RS-485 (default), RS-232/SDI-12/RS-422 (optional)

Communication protocol

Theta ASCII (Optonal), MODBUS, SDI-12,NMEA (Optional)

Power

12mA@ 12VDC, 10A@24VDC (with heating)

Operating voltage

12 … 30VDC

Operating temperature

-40 … +70℃

Operating humidity

5% … 100%RH

Connector

8Pin

Cable

PUR 5m




Technical Parameters

Wind Speed

Principle

Ultrasonic

Measurement range

0 … 60m/s

Accuracy

±0.3 m/s or 3% of reading, whichever is greater

Resolution

0.1m/s

Wind Direction

Principle

Ultrasonic

Measurement range

0 … 359.9°

Accuracy

±3°

Resolution

 0.1°
